Product Description
Keyboard Pad Mobile Barcode Scanner PDA For Mitsubishi Elevator PDA IP66 Data Capture T80 PDA With 4.5 Inch Screen 16GB
Please pay attention:this product link is for based features only,NOT including barcode scanner or NFC.

MT80 Android PDA Barcode Scanner is the best choice of hand-held terminal for enterprise users to collect data due to its classic Android APPs and aggressive performance,which is usually applied in the fields including government & public affairs, financial management, ticket business,traceability, medicare,logistics, retailing stores and supermarkets, O2O e-commerce payment, etc.






Android PDA Barcode Scanner
|
||
Performance
|
||
CPU
|
Cortex-A53 Quad-core 64-bit 2.0GHz high-performance processor
|
|
RAM+ROM
|
2GB+16GB Supports up to 3GB+32GB
|
|
Expand memory
|
Micro SD(TF) Supports up to 128GB
|
|
System
|
Android 8.1/Android 9.0
|
|
Data Communication
|
||
WLAN
|
Dual-band 2.4GHz / 5GHz, Supporting IEEE 802 a/b/g/n/ac protocol
|
|
WWAN
|
2G:GSM(850/900/1800/1900MHz);3G:WCDMA(850/900/1900/2100MHz);4G:FDD:B1/B3/B4/B7/B8/B12/B20;TDD:B38/B39/B40/B41
|
|
BT
|
Support BT 2.1+EDR/3.0+HS/4.1+HS Transmission distance 5-10 meters
|
|
GPS
|
Support GPS, Galileo, Glonass, Beidou
|
|
Physical Parameter
|
||
Dimensions
|
166mm×77.5mm×22mm
|
|
Weight
|
<500g
|
|
Display
|
4.5 inch IPS color display with resolution 480*854
|
|
TP
|
Corning Gorilla glass, supports multi-touch Supported gloves and wethands
|
|
Battery capacity
|
Rechargeable polymer battery (3.7V 4200mAh) removable;Standby time >350 hours;Working time > 12 hours;Charging time <4H, using standard power adapter and data cable
|
|
Expansion Card slot
|
PSAM x 2, Micro SIM card x 1 , TF card × 1;POGO Pin x 1
|
|
Communication interface
|
Type-C USB x 1, OTG
|
|
Audio
|
Speaker (mono), Microphone, Earpiece
|
|
Keypad
|
Support touch screen soft keypad and physical keypad
|
|
Sensor
|
Gravity sensor, Vibration motor
|
|
Data Collection
|
||
Barcode scanning (Optional)
|
||
1D Linear canner
|
Mindeo SE966 Honeywell N4313 Newland EM1300(CCD)
|
|
1D Symbologies
|
Code128,EAN-13,EAN-8,Code39,UPC-A,UPC-E,Codaber,Interleaved 2 of 5,China post 25,ISBN/ISSN,Code93,UCC/EAN-128, GS1 Databar,HIBC, etc.
|
|
2D Imager canner
|
Newland EM3090 Newland EM6601 Honeywell N6603
|
|
2D Symbologies
|
PDF417,Micro PDF417,GS1 Composite,Aztec Code,Data Matrix,QR Code,Micro QR Code,MaxiCode,Hanxin Code, etc.
|
|
Rear camera
|
8MP HD camera,Support auto focus, Flash, Anti-shake, Macro shooting
|
|
NFC (optional)
|
||
Frequency
|
13.56MHz
|
|
Protocol
|
Support ISO14443A/B, 15693 agreement
|
|
Distance
|
2cm-5cm
|
|
User environment
|
||
Operating temperature
|
-20℃ – 55℃
|
|
Storage temperature
|
-40℃ – 70℃
|
|
Environment humidity
|
5%RH–95%RH(no condensation)
|
|
Drop specification
|
6 sides Supports 1.5 meters drops and 30 times to the concrete within the operating temperature
|
|
Rolling test
|
500×0.5m rolling for 6 sides
|
|
Protection level
|
IP66
|
|
Accessories
|
||
Standard
|
Adapter, Data cable, Protective film, Instruction manual
|
Product Features(Android PDA Barcode Scanner)
>>>>High-speed operation performance: With androd 7.0 operating system, matching 64 bit quad core 1.3GHz high speed processor with prefect compatibility and computing capability, high-speed operating efficiency is suitable for strict application requirement.
>>>>Excellent identification ability : Fully support 1D and 2D barcode scanning,NFC(optional).
>>>>Convenient appearance design: Slim and ergonomics design, it is convenient and comfortable for holding and carrying. 4.5 inch Screen Work even with water or Gloves.
>>>>Abundant means of data transportation(option) 2G,3G,4G,Wifi,BT,etc.
>>>>Industrial grade durability: IP66 industrial grade, solid and light body can bear the height of 1.2m dropping and 1000 times tumbled within the scope of 0.5m. Waterproof,dustproof provide long time using without fatiguet.
>>>>HD Camera: Postposition 8 mega pixel autofocus camera, is convenient for client to collect all kind of images and video.
>>>>Multiple extensions: Support GPS , AGPS and Beidou compass navigation.
>>>>Always-available wireless connection: Supports 802.11 a/b/g/n full-band wireless communications and maintains real-time connection with the system to ensure high efficient operation.
>>>>Excellent identification ability : Fully support 1D and 2D barcode scanning,NFC(optional).
>>>>Convenient appearance design: Slim and ergonomics design, it is convenient and comfortable for holding and carrying. 4.5 inch Screen Work even with water or Gloves.
>>>>Abundant means of data transportation(option) 2G,3G,4G,Wifi,BT,etc.
>>>>Industrial grade durability: IP66 industrial grade, solid and light body can bear the height of 1.2m dropping and 1000 times tumbled within the scope of 0.5m. Waterproof,dustproof provide long time using without fatiguet.
>>>>HD Camera: Postposition 8 mega pixel autofocus camera, is convenient for client to collect all kind of images and video.
>>>>Multiple extensions: Support GPS , AGPS and Beidou compass navigation.
>>>>Always-available wireless connection: Supports 802.11 a/b/g/n full-band wireless communications and maintains real-time connection with the system to ensure high efficient operation.
Details Images



Industrial Applications

MSENCH introduces barcodes and RFID into logistics management, and integrates the work of receiving, sorting (allocation), distribution, and dispatching through logistics PDA to realize intelligent work and management. The key data such as the time point of the link and the responsible person are collected in real time and collected on a unified information platform. Managers can obtain and manage information in real time through the background, and support users to view logistics tracking information, which is efficient and convenient, which not only greatly improves the efficiency of logistics operations, Reducing logistics costs is also conducive to improving user service experience and increasing satisfaction.
